Machines for the casting floor.
One printer in production today, and a manufacturing platform being built around it — desktop printing, diamond cutting, materials and software.
In production
Uniway NEO3
High quality 3D wax patterns for investment, precision and shell casting — 8 µm and 15 µm layers, straight off the platform, with no mould tooling anywhere in the process.
The NEO3 introduces a triple print-head array over the widest platform in its class, paired with automatic build-plate changing so the machine keeps working through unattended shifts. It is designed for the operations that measure output in trays per week, not parts per day.
| Technology | MJP — multi-jet wax printing |
|---|---|
| Build platform | 450 × 210 × 120 mm |
| Layer thickness | 8 µm / 15 µm |
| Print heads | 3, fixed head design |
| Material | 100% castable wax |
| Build plate handling | Automatic plate changer, 24/7 operation |
| Machine dimensions | 1620 × 740 × 1400 mm |
| Control | Onboard touchscreen, networked, AI-ready |
| Print resolution | On request |
Why it holds up in production
- Fixed print heads. No moving carriage assembly to drift out of alignment — stable jetting and a long working life.
- Three heads, one pass. Roughly 50% more output than a comparable single-array machine over the same platform.
- Unattended running. The plate changer swaps completed builds automatically, so a queued job list runs overnight.
- Clean burnout. 100% castable wax leaves no residue in investment and shell casting shells.
- Detail that survives casting. 8 µm layers give sharp edges and smooth rounded surfaces that carry through to the metal.
Site requirements
A UPS rated at 3 kVA minimum, washing and drying equipment, isopropyl alcohol for post-processing, and a temperature-controlled room. We will walk through the full installation checklist with you before delivery.
From wax to metal
One workflow, four steps
Printed patterns drop into the investment casting process you already run. Nothing downstream has to change.
STEP 01
Design
CAD model or 3D scan, nested onto the platform in our software.
STEP 02
Print in wax
The NEO3 jets 100% castable wax in 8 µm layers. Wash and dry, and the pattern is ready.
STEP 03
Invest & burn out
Tree, invest and burn out exactly as you would with an injected wax pattern.
STEP 04
Cast
Pour, break out and finish. No mould tooling, no minimum quantity, no lead time on a design change.
Proven on
Industries running NEO patterns
Dental
Copings, crowns, bridges and press patterns from scan data.
Engineering
Topology-optimised brackets and short-run cast components.
Industrial
Impellers, turbine blades and complex internal passages.
Medical
Anatomical casts and patient-specific patterns.
Art & restoration
Sculpture, ornament and heritage replacement parts.
In development
What comes next
Infinity is extending the range beyond industrial printing. These products are in development — talk to us if you would like to be an early evaluation partner.
Desktop MJP
Multi-jet wax printing in a benchtop machine, for studios, dental laboratories and design offices that do not need a production platform.
CNC diamond cutting
Diamond cutting and faceting equipment for jewellery manufacturers, engineered to the same tolerances as our printing systems.
Wax & resin materials
Castable wax and photopolymer resin formulated for our machines and validated against real burnout and casting cycles.
CAM software
Nesting, support generation and toolpath control written by the team that built the hardware, so the two stay in step.
Send us a part
The fastest way to judge a printer is to see your own geometry come off it. Send a file and we will print it, cast it if you like, and send it back.
